SKU: NAO9x22x12-EU
NAO9x22x12 Budget Needle Roller Bearing Without Flanges and With Shaft Sleeve
NAO9x22x12 Budget Needle Roller Bearing Without Flanges and With Shaft Sleeve
Regular price
£8.02
ex VAT£9.62inc. VAT
Regular price
Sale price
£8.02
ex VAT£9.62
inc. VAT
In stock
Price Break
10+
£7.14
19+
£6.74
29+
£6.66
39+
£6.58
49+
£6.50
74+
£6.42
99+
£6.02
199+
£5.94
249+
£5.86
499+
£5.78
999+
£5.62
Description
Description
|
Budget Flange-less Needle Roller: The flange-less design permits separation of the supplied inner ring and the outer bearing to facilitate ease of mounting. Benefits: Separable, ease of mounting. |
- Brand / Quality:
- EU Budget - Economy Quality
- Inside Diameter:
- 9mm
- Outside Diameter:
- 22mm
- Width:
- 12mm
Technical
Technical
| d | 9mm |
|---|---|
| D | 22mm |
| B | 12mm |
| Dynamic load C | 9520 N |
| Static load Co | 10000 N |
| Fatigue load limit Pu | 1180 N |
| Speed in grease | 17000 rpm |
| Speed in oil | 26000 rpm |
| E | 18mm |
| F | 12mm |
| r1r2 min | 0.3mm |
| S (axial disp) | 0.5mm |
| da | 17.6mm |
| db | 11.7mm |
| Da | 18.3mm |
| Db | 12.3mm |
| ra max | 0.3mm |
| Weight | 24 g |
