SKU: NAO17x30x13-EU
NAO17x30x13 Budget Needle Roller Bearing Without Flanges and With Shaft Sleeve
NAO17x30x13 Budget Needle Roller Bearing Without Flanges and With Shaft Sleeve
Regular price
£14.63
ex VAT£17.56inc. VAT
Regular price
Sale price
£14.63
ex VAT£17.56
inc. VAT
In stock
Price Break
10+
£13.02
19+
£12.29
29+
£12.14
39+
£11.99
49+
£11.85
74+
£11.70
99+
£10.97
199+
£10.82
249+
£10.68
499+
£10.53
999+
£10.24
Description
Description
|
Budget Flange-less Needle Roller: The flange-less design permits separation of the supplied inner ring and the outer bearing to facilitate ease of mounting. Benefits: Separable, ease of mounting. |
- Brand / Quality:
- EU Budget - Economy Quality
- Inside Diameter:
- 17mm
- Outside Diameter:
- 30mm
- Width:
- 13mm
Technical
Technical
| d | 17mm |
|---|---|
| D | 30mm |
| B | 13mm |
| Dynamic load C | 10100 N |
| Static load Co | 16300 N |
| Fatigue load limit Pu | 1860 N |
| Speed in grease | 12000 rpm |
| Speed in oil | 18000 rpm |
| E | 26mm |
| F | 22mm |
| r1r2 min | 0.3mm |
| S (axial disp) | 0.5mm |
| da | 25.6mm |
| db | 21.5mm |
| Da | 26.3mm |
| Db | 22.4mm |
| ra max | 0.3mm |
| Weight | 42 g |
